Shunt Reactor Test System
Shunt Reactor Test System (ISRTL)
A Systematic way to test the shunt reactor
SRTS is a fully integrated test suite for testing of reactors up to 1000Amp. SRTS also used to test the magnetization characteristics of the reactor core.
Benefits of SRTS
Automated data acquisition ensures error free data logging and assists in carrying out statistical analysis of test results.
It allows users to easily store and retrieve data with simple but intuitive graphical user interface.
Linearity Test Bench
(complying with IEC 60076—6)
Tests Covered by ISRTL
| Sr.No | Tests |
|---|---|
| 1 | Measurement Of Load Loss And Impedance At Cold Condition |
| 2 | Measurement Of Load Loss And Impedance At Hot Condition |
| 3 | Measurement Of Impedance By V-i Method |
| 4 | Measurement Of Vibration Level |
| 5 | Measurement Of Stress Level |
| 6 | Measurement Of Volt-ampere Characteristics Of Shunt Reactor (Magnetic Characteristics Of Shunt Reactor) |
| 7 | Temperature Rise Test |
| 8 | Dga Test On Oil Before And After Temperature Rise Test |
| 9 | Measurement Of Capacitance And Dissipation Factor |
| 10 | Measurement Of Harmonics |
| 11 | Measurement Of Acoustic Noise Level |
| 12 | Measurement Of Zero Phase Sequence Impedance |
| 13 | Lightening Impulse Voltage Withstand Test |
| 14 | Lightening Impulse Voltage Withstand Test For Neutral Winding |
| 15 | Measurement Of Winding Resistance |
| 16 | Measurement Of Insulation Resistance |
| 17 | Switching Impulse Voltage Withstand Test |
| 18 | Separate Source Voltage Withstand Test |
| 19 | Induced Over Voltage Withstand Test With Partial Discharge |
| 20 | Isolation Test |
Linearity Test System Schematic
