Transformer Test Pro (TTP) Software for Transformer Testing

A Graphical User Interface, Data Acquisition (DAQ) & Report Generation Software, to increase the Productivity, Consistency, Reliability of Testing of Transformers of all ratings up to 900 MVA

Features of TTP Software

Inbuilt drivers for automatic measurements acquisition from any type of communicable Test Instrument. Allows editing & entering measurements manually

Gives alarms for invalid or incorrect measurements

Easy storage & retrieval of all the test reports

Prints Test Report complying with IS, IEC, ANSI & SABS

Auto indexing & page numbering of test reports as selected test sequence

Analysis Report facility

Prints detailed test report, short test report & extra short report with single page.

Facility of printing formulae sheet when required

Suggests Capacitor Bank Connection

Instant data back-up facility

ERP Integration

Remote On-line test witness

Benefits of TTP Software

Reduction in testing process time

Instant error-free calculations, report generation & printing

Increases the testing productivity

TTP Software Suitable For Testing Of

Measurement Of Voltage Ratio And Check Of Phase Displacement>
Generator Transformer Power Transformer Furnace Transformer
Station Transformer Auto Transformer Rectifier Transformer
Dry Type Transformer Neutral Ground Transformer Unit Auxiliary Transformers
Distribution Transformer Locomotive Transformer 1

TTP Software Suitable For Testing Of Transformers With

Parameters TTP suitability for
Conductor Aluminum / Copper
Phases 1 /3
Windings 2 / 3 / 4 / Auto / Unloaded Tertiary / Single / Dual / Split / Zigzag / Fork connection Auto Transformer
Vector Group All, Single / Dual
Cooling ONAN / ODAF / ODWF / OFAF / ONAF / ANAF / ANAN / AN
Testing Options Final / Internal / Stage / After short circuit / Before short circuit / Customer witness inspection

Tests Covered By TTP Software

Sr.No. Tests
1 Measurement Of Voltage Ratio And Check Of Phase Displacement
2 Measurement Of Winding Resistance
3 Measurement Of Insulation Resistance
4 Measurement Of No Load Loss And No Load Current
5 Test To Prove Over fluxing Capability / Oil Soaking Test
6 Measurement Of Load Loss And Impedance Voltage
7 Three Winding Losses Of Three Phase Transformer
8 Measurement Of Impedance Voltage
9 Measurement Of Single Phase Impedance
10 Calculation Of Efficiency And Regulation
11 Separate Source Voltage Withstand Test
12 Induced Over Voltage Withstand Test (Uniform / Non Uniform Insulaion Method)
13 Induced Over Voltage Withstand Test With Partial Discharge
14 Magnetic Balance And Magnetizing Current Test
15 MEASUREMENT OF NO LOAD LOSS & NO LOAD CURRENT AT LOW VOLTAGE
16 Measurement Of Load Loss And Imped. Voltage With Spill Current
17 Measurement Of Load Loss And Impedance Voltage At Low Voltage
18 Measurement Of Single Phase / Three Phase Short Circuit Impedance
19 Magnetic Circuit Test
20 Check Of CT Ratio And Polarity
21 Excitation Current Measurement
22 OLTC Motor Current Measurement
23 Check Of CT Knee Point Voltage
24 Check Of CT DC Resistance
25 Tests On On – Load Tap Changer (OLTC)



Sr.No. Tests
26 Measurement Of Capacitance And Dissipation Factor
27 Measurement Of Harmonics
28 Measurement Of Acoustic Noise Level
29 Measurement Of Power Taken By Cooler Circuit
30 Measurement Of Zero Phase Sequence Impedance
31 RSO Test
32 Lightening Impulse Voltage Withstand Test
33 Lightening Impulse Voltage Withstand Test For Neutral Winding
34 Measurement Of Transferred Surge Voltage
35 Temperature Rise Test For Overloading Cycle
36 DGA Test On Oil Before And After Temperature Rise Test
37 Oil BDV Test
38 Water Content Test
39 Measurement Of Vibration Of Transformer At Rated Excitation
40 Functional Checks Of Control Panels
41 Switching Impulse Voltage Withstand Test
42 Oil Leakage Test
43 Pressure Deflection Test
44 Vacuum Deflection Test
45 Test On Pressure Relief Device
46 Jacking Test
47 Measurement Of Oil Quantity For First Oil Filling
48 Visual Inspection And Dimensional Test On Assembled Transformer
49 Calibration Of WTI & OTI
50 Frequency Response Analyser
51 Thermal Imaging
52 Dew Point Measurement
Order Code

TTP-R – Transformer Test Pro Software for Routine Tests.
TTP-RH – Transformer Test Pro Software for Routine & Heat Run Tests
TTP-F – Transformer Test Pro Software for Routine, Type and Special Tests


Suffix

E- Transformer Test Pro Software with ERP integration
W- Transformer Test Pro Software with Website integration

List of Test Instruments supported by TTP Software for Automatic Data Acquisition

Insulation Tester
Sr.No Manufacturer
1 AVO
2 MEGGER-MIT1020
3 MEGABRAS-MD5060e
4 MOTWANE 5KPIV4
5 MEGGER-MIT525
6 SIVANDA IR5K4
7 MEGABRAS-MD5060e
8 GW-INSTEK
Resistance Meter
Sr.No Manufacturer
1 LMS
2 YOKOGAWA - WT3000
3 YOKOGAWA - WT230
4 YOKOGAWA - WT330
5 YOKOGAWA - WT333
6 Veer
7 YOKOGAWA - WT500
8 HIOKI- 3337
Power Analyser
Sr.No Manufacturer
1 RAYTECH WR-50
2 TINSLEY 5896C
3 MOTWANE XWRM-10
4 PRESTIGE
5 RAYTECH WR-14
6 RTF
7 TWRM-10A
8 TRM25
9 TWRM-10A
10 GW-INSTEK
Oil BDV Tester
Sr.No Manufacturer
1 SIVANANDA-OIL/BDV
2 MEGGER-OTS100AF/2
3 SIVANANDA-OIL/BDV
4 MEGGER-OTS100AF/2
Temperature Scanner
Sr.No Manufacturer
1 NIPPON
2 RADIX
3 YOKOGAWA
4 SCHNEIDER
Ratio Meter
Sr.No Manufacturer
1 SIVANANDA ATRM-1(UP)
2 RRAYTECH TR-MARK IIIR
3 UDEY RATIO METER
4 Tinsley 4167F
5 SIVANANDA
6 TINSLEY 4167D
7 RAYTECH-TR SPY
GUI Report Format Brochure
